CC- 1 CF Center Channel

CC – 1CF center channel is compact yet powerful. Designed to deliver high performance it boasts a 3/4" thick front baffle, polypropylene capacitors and air cored inductors.. Total height is just under 5.5”. Dual 4” woven carbon fibre mid-bass drivers in conjunction with a high performance textile tweeter, provide excellent full range performance wide dispersion and dialogue intelligibility.A rear mounted volume control provides precise high frequency level adjustment for virtually any room or electronics.. The front driver panel is angled 11 degrees for optimum placement either above or below TV screen.

  Specifications

System Design     Dual 4 “ WTW  Shielded Center Channel

Woofers 2 ea  4 “ carbon fibre shielded

Tweeter  1 ea  ¾” shielded Vifa textile dome

Crossover                             Minimum phase 2.2 khz

Frequency Resp   55 hz to 20 khz

Sensitivity      89 db

Power Min/ Max    10 W – 120 W

Impedance     6 Ohms

Dimensions   5.5 ” h x 17” w x 7/ 6 “ d – 11 deg angle

FinishesBlack gloss, Flat Black, Cherry (shown above)

      Shown in Dark Red Cherry

Source Technologies 701 Nutmeg Road N., South Windsor,  Conn. 06074

(800) 599 7558
